River Dredging Diesel Amphibious Dredger 500m3/h Working Capacity
| Place of Origin | Shandong china |
|---|---|
| Brand Name | Keda |
| Certification | CE 9001 |
| Minimum Order Quantity | 1 |
| Price | $58,000/sets >=1 sets |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Video Outgoing-inspection | Provided | Machinery Test Report | Not Available |
|---|---|---|---|
| Core Components | Engine, Pump | Working Capacity | 500m³/h |
| Type | Sand Dredger | Power Type | Diesel |
| Dredging Depth | 5 M | Draught | 100 Cm |
| Dimension(L*W*H) | 9*3.9*3.5 | Weight | 20000 KG |
| Warranty | 1 Year | Color | Customer's Request |
| Application | River Dredging | After-sales Service Provided | Overseas Service Provided |
| Usage | Port River Lake Sea | ||
| Highlight | Diesel Powered Amphibious Dredger,500m³/h Working Capacity Amphibious Dredger,500m3/h River Dredging Machine |
||
Product Description
Dredging Depth 5m and Draught 100cm Hydraulic Cutter Suction Sand River Excavator with Multi-Function Amphibious Dredger
Product Description
This multi-purpose excavator is designed for land, swamp soft ground, and shallow water environments. The walking system features a multihull pontoon structure with sealed box-shaped track shoes, enabling safe operation on silt and water surfaces.
The front attachment system supports interchangeable tools including gun heads, reamer heads, and buckets, ensuring work quality and digging efficiency while enhancing operational convenience. The advanced hydraulic system paired with the power unit enables compound operations, balancing high efficiency with economic performance.
Product Parameters
The Pontoon Undercarriage
| Parameter | Specification |
|---|---|
| Model of Pontoon Undercarriage | JY200 |
| Travel Motor Assembly | DOOSANTM60VCx2 |
| Pontoon and Track Shoe Material | Q355B Reinforced Steel |
| Pontoon Thickness | Bottom 6mm, Side 4mm |
| Chains per Pontoon | 3 track chains |
| Chain Material | 40Cr Hard-wearing Steel |
| Pontoon Dimensions | Single: 10000mm×1970mm×1840mm Connected: 10000mm×5200mm×1840mm |
| Anti-rust Technology | Environmental shot blasting for extended service life |
| Color | Grey |
| Pressing Technology | Enhances pontoon strength while reducing weight and improving buoyancy |
Side Pontoons with Spuds
- Side pontoon dimensions: 7×1.5×1m (each)
- Spud length: 8m
- 2 hydraulic full automatic spuds
- Motor-assisted spud operation via oil cylinder - simple switch control
Product Gallery
Company Profile
Qingzhou Keda Mining Machine Co., Ltd. specializes in mineral processing equipment including dredgers, sand washing systems, gold panning equipment, and crushers. With independent R&D capabilities and dozens of patents, we provide customized solutions for diverse geographical conditions.
Frequently Asked Questions
Who are we?
We are a Shandong-based manufacturer specializing in aquatic and amphibious equipment since 2011, with 51-100 employees. Our product range includes dredgers, amphibious excavators, aquatic weed harvesters, and gold panning equipment.
How do we guarantee quality?
We conduct pre-production samples and final inspections before shipment to ensure product quality.
What products do we offer?
Dredgers, gold mining equipment, water weed harvesters, and sand production systems.
Why choose us?
We specialize in mineral processing equipment with patented technologies, offering comprehensive services from R&D to after-sales support for global markets.
What services do we provide?
- Delivery Terms: FOB, CFR, CIF, EXW, CIP
- Payment: USD, EUR via T/T, L/C, Credit Card, Western Union, Cash
- Languages: English, Chinese
